The Hydra-Lock Quick Change Cartridge system consists of a sleeve and stop ring assembly with accuracy of 5 microns for use over a basic hydraulic arbor or in a chuck or fixture. This allows the customer to purchase one basic tool to hold multiple parts during the machining or manufacturing process and maintain excellent accuracy.

The Hydra-Lock Parallel Sleeve

The Hydra-Lock Parallel sleeve has the same accuracy of 5 microns and is used when the part stops and sleeve is one detail. It is also used over a basic hydraulic arbor, or, in a chuck or fixture to hold multiple parts.

Quick Change Chuck

Our Quick Change Chuck™ is permanently mounted on a machine spindle and the replaceable Hydra-Lock tool has a journal OD that is inserted in the Quick Change Chuck™ ID.  It is then locked into place by turning a hand actuate screw. The replaceable Hydra-Lock tool is now centered and has a TIR of 5 microns or less with no indicating.

Accuracy and Precision

As the case with all our products, all these designs for the Aerospace industry will hold parts securely while resisting the tooling forces generated in your operation and repeat within 1 micron.

Take the Next Step

To inquire about our quick change tooling services for the Aerospace industry please contact us at sales@hydralock.com or call (800) 634-6973.
